les Specs du JL :
http://www.jlwranglerforums.com/forum/t ... pers.2073/
ENGINE: 3.6-LITER PENTASTAR V-6
Available: Standard on all models
Type: 60-degree, V-type, liquid-cooled
Displacement (cu. in. / cc): 220 cu. in. (3,604 cu. cm)
Bore x Stroke: 3.78 x 3.27 (96 x 83)
Valve System: Chain-driven DOHC, 24 valves and hydraulic end-pivot roller rockers
Fuel Injection: Sequential, multiport, electronic, returnless
Construction: Aluminum deep-skirt block, aluminum alloy heads
Compression Ratio: 11.3:1
Power (SAE net) (hp / kW@rpm): 285 hp (209 kW) at 6,400 rpm
Torque (SAE net) (lb.-ft. / N•m): 260 lb.-ft. (353 N•m) at 4,800 rpm
Max. Engine Speed (rpm): 6,600 rpm (electronically limited)
Fuel Requirement: Unleaded regular, 87 octane (R + M)/2
Fuel Tank Capacity (gallons): 18.5 (2-door), 21.5 (4-door)
Oil Capacity: 5.0 quarts (4.7 liters)
Coolant Capacity: 10 quarts (10.1 liters)
Emission Controls: Dual three-way catalytic converters, heated oxygen sensors and internal engine features
Max. Gross Trailer Weight: 2,000 lbs. (2-door), 3,500 lbs. (4-door)
EPA Fuel Economy mpg (city/hwy/combined): 18/23/20 (automatic); 17/23/19 (manual)
Assembly Plant: Saltillo South Engine Plant, Saltillo, Coahuila, Mexico
ENGINE: 2.0-LITER TURBO I-4
Availability: Optional — all models
Type: I-4 16-valve with direct injection, turbo charging, with throttled, cooled EGR
Displacement (cu. in. / cc): 121 cu. in. (1995 cu. cm)
Bore x Stroke: 3.31 x 3.54 (84 x 90)
Valve System: Chain-driven DOHC, 16 valves
Fuel Injection: Direct Injection
Construction: Aluminum block, aluminum alloy heads
Compression Ratio: 10:01
Power (SAE net) (hp / kW@rpm): 270 hp (200 kW) at 5,250 rpm
Torque (SAE net) (lb.-ft. / N•m): 295 lb.-ft. (400 N•m) at 3,000 rpm
Max. Engine Speed (rpm): 5,800 rpm (electronically limited)
Fuel Requirement: Minimum unleaded regular, 87 octane (R + M)/2, 91 octane or higher recommended for optimum fuel economy and performance
Fuel Tank Capacity (gallons): 18.5 (2-door), 21.5 (4-door)
Oil Capacity: 5 quarts (4.7 liters)
Coolant Capacity: 9.9 quarts (9.4 liters)
Emission Controls: GPEC4 engine-management system with close-coupled catalyst; and wide range O2 sensor
Max. Gross Trailer Weight: 2,000 lbs. (2-door), 3,500 lbs. (4-door)
EPA Fuel Economy mpg (city/hwy/combined): TBD — automatic (2-door); TBD — automatic (4-door)
Assembly Plant: Termoli, Italy and Trenton South Engine Plant, Trenton, Mich.
ENGINE: 3.0 LITER ECODIESEL V-6
260 horsepower, 442 lb-ft of torque
"More robust" 8-speed automatic transmission only
Available on 4-door only
TRANSMISSION: 850RE AUTOMATIC, EIGHT-SPEED OVERDRIVE
Availability: Standard — 2.0-liter I-4; Optional — 3.6-liter V-6
Description: Adaptive electronic control or Electronic Range Select (ERS) driver-interactive manual control and electronically modulated torque converter clutch
Gear Ratios:
1st - 4.71
2nd - 3.13
3rd - 2.10
4th - 1.67
5th - 1.28
6th - 1.00
7th - 0.84
8th - 0.67
Reverse - 3.53
TRANSMISSION: D478 MANUAL, SIX-SPEED WITH OVERDRIVE
Availability: Standard — 3.6-liter V-6
Description: Synchronized in all forward gears and Reverse, multi-rail shift system with top-mounted shift lever
50% shorter throws
Gear Ratios:
1st - 5.13
2nd - 2.63
3rd - 1.53
4th - 1.00
5th - 0.81
6th - 0.72
Reverse - 4.49
Final Drive ratio - 3.45 standard, 3.73 optional (4.10 Rubicon)
TRANSFER CASE: NV241 COMMAND-TRAC
Available: Standard on Sport and Sahara
Type: Part-time
Operating Modes: 2WD High; 4WD High; Neutral; 4WD Low
Low Range Ratio: 2.72:1
TRANSFER CASE: NV241OR ROCK-TRAC
Available: Standard on Rubicon
Type: Part-time
Operating Modes: 2WD High; 4WD High; Neutral; 4WD Low
Low Range Ratio: 4.0:1
TRANSFER CASE: MP3022 SELEC-TRAC
Available: Optional – Sahara
Type: Full-time
Operating Modes: 2WD High; 4WD High; Neutral; 4WD Low
Low Range Ratio: 2.72:1
AXLES
Front: Dana 30, Dana 44 on Rubicon models
Differential Type: Open (Dana 30) or Tru-Lok electronic locking (Dana 44)
Axle Ratios: 3.45, 3.73, 4.10
Rear: Dana 35, Dana 44 on Rubicon models
Differential Type: Open (Sport and Sahara) with available Trac-Lok anti-spin, Tru-Lok electronic locking (Rubicon)
Axle Ratios: 3.45, 3.73, 4.10
ELECTRICAL SYSTEM
Alternator (standard): 160 amp
Battery: 600 CCA, maintenance free
SUSPENSION
Front: Solid axle, link coil, leading arms, track bar, coil springs, stabilizer bar
Stabilizer bar: Electronic sway-bar disconnect system — standard, Rubicon
Shock type:
Sport: Gas charged twin tube shock absorbers with full displacement Multi-Tuned Valve (MTV) technology
Sahara: High pressure gas charged monotube shock absorbers with MTV technology
Rubicon: High pressure gas charged monotube shock absorbers with MTV technology and hydraulic rebound stop
Rear: Solid axle, link coil, trailing arms, track bar, coil springs, stabilizer bar
Shock type:
Sport: Gas charged twin tube shock absorbers with full displacement MTV technology
Sahara: High pressure gas charged monotube shock absorbers with MTV technology
Rubicon: High pressure gas charged monotube shock absorbers with MTV technology and hydraulic rebound stop
STEERING
Type: Electro-hydraulic Power
Overall Ratio: 17.4:1 – 2-door, 15.6:1 – 4-door
Turning Diameter (curb-to-curb) (ft./m): 34.5 2-door, 40.8 4-door
Steering Turns (lock-to-lock): 3.6 -2-door, 3.2 4-door
P/S pump: Electro-Hydraulic
BRAKES
Type: Power-assisted, anti-lock braking system
Availability: Standard
Front
Rotor size and type:
12.9 x .94 (330 x 24) vented rotor – Sport
12.9 x 1.1 (330 x 28) vented rotor – Sahara and Rubicon
Caliper size and type:
1.88 (48) twin-piston floating caliper – Sport
2 (51) twin-piston floating caliper – Sahara and Rubicon
Rear:
Rotor size and type:
12.9 x .47 (328 x 12) solid rotor – Sport
13.4 x .55 (342 x 14) solid rotor – Sahara and Rubicon
Caliper size and type:
1.77 (45) single-piston floating caliper – Sport
1.88 (48) single-piston floating caliper – Sahara and Rubicon
DIMENSIONS AND CAPACITIES
Wheelbase: 2-door 96.8 (2,460), 4-door 118.4 (3,008)
Overhang — Front: 29.2 (741.6)
Overhang — Rear: 40.8 (1,036.3)
Track — Front: 62.9 (1,598)
Track — Rear: 62.9 (1,598)
Overall Length (includes spare tire): 166.8 (4,237) – 2-door, 188.4 (4,785) – 4-door
Overall Width: 73.8 (1,875)
Overall Height: 73.6 (1,868.4)
Liftover Height: 29.7 (756.4)
Cargo Width at Swing-Gate Opening: 41.1 (1,052)
Cargo Height at Swing-Gate Opening: 36 (942.3)
Load Floor Height: 30 (762.1)
CLEARANCES
245/75R17 (Standard on Sport)
Approach Angle (degrees): 41.4
Breakover Angle (degrees): 25 (2-door); 20.3 (4-door)
Departure Angle (degrees): 35.9 (2-door); 36.1 (4-door)
Ground Clearance (inches): 9.7
255/70R18 (Standard on Sahara)
Approach Angle (degrees): 41.8
Breakover Angle (degrees): 21
Departure Angle (degrees): 36.1
Ground Clearance (inches): 10
LT28570R17 (Standard on Rubicon)
Approach Angle (degrees): 44 (2-door); 43.9 (4-door)
Breakover Angle (degrees): 27.8 (2-door); 22.6 (4-door)
Departure Angle (degrees): 37
Ground Clearance (inches): 10.8
CURB WEIGHT
2.0-liter (2- and 4-door)
Wrangler Sport
Automatic Transmission (lbs./kg): 4,010 (1,819)
Manual Transmission (lbs./kg): N/A
Wrangler Sahara
Automatic Transmission (lbs./kg): 4,380 (1,987)
Manual Transmission (lbs./kg): N/A
Wrangler Rubicon
Automatic Transmission (lbs./kg): 4,175 (1,894)
Manual Transmission (lbs./kg): N/A
3.6-liter (2- and 4-door)
Wrangler Sport
Automatic Transmission (lbs./kg): 3,955 (1,794) / 4,200 (1,905)
Manual Transmission (lbs./kg): 3,970 (1,801) / 4,215 (1,912)
Wrangler Sahara
Automatic Transmission (lbs./kg): 4,345 (1,971)
Manual Transmission (lbs./kg): N/A
Wrangler Rubicon
Automatic Transmission (lbs./kg): 4,145 (1,880) / 4,455 (2,021)
Manual Transmission (lbs./kg): N/A
ACCOMMODATIONS
Seating Capacity (front/rear): 2/2 – 2-door, 2/3 – 4-door
SAE Total Interior Passenger Volume, (cu. ft. / cu. m): 103.7 (2.94)
Front:
Headroom: 40.7 (1,036) hardtop / 42.6 (1,083) soft top
Legroom: 41.2 (1,038)
Shoulder Room: 55.7 (1,417)
Hip Room: 53.9 (1,370)
Seat Travel: 8.1 (206)
EPA Front Volume Index: 53.8 (1.52)
Rear:
Headroom: 40.2 (1,023) hardtop, 41.7 (1,059) soft top
Legroom: 35.7 (904.2) – 2-door, 38.3 (974) – 4-door
Knee Clearance: 61.6 (1,565.9)
Shoulder Room: 57.7 (1,458) – 2-door, 55.7 (1,417) – 4-door
Hip Room: 45 (1,143) – 2-door, 56.7 (1,440) – 4-door
EPA Rear Seat Volume Index (cu. ft. / cu. m): 49.9 (1.40)
Liftover Height: 29.7 (756.4)
Maximum Cargo Width at Liftgate Opening: 47.9 (1,218.7)
Minimum Cargo Width at Liftgate Opening: 41.1 (1,052)
Maximum Cargo Height at Liftgate Opening: 36.0 (942.3)
Minimum Cargo Height at Liftgate Opening: 35.7 (907.

Distance between Wheelhouse Interior Trim: 45.0 (1143)
SAE Cargo Volume:
Rear Seat Folded: 72.4 cu. ft. (2.05)
Rear Seat Upright: 31.7 cu. ft. (0.89)
Total Passenger plus Cargo Volume, (cu. ft. / cu. m): 150.4 cu. ft.
WHEELS
Standard (Sport)
Painted steel, Low Gloss Black painted
Size 17 x 7.5 in.
Sport S (Standard)
Fully painted cast-aluminum with High Gloss Tech Silver
Size 17 x 7.5 in.
Sport S (Optional)
Painted and polished cast-aluminum with Low Gloss Granite Crystal
Size 17 x 7.5 in.
Sahara (Standard)
Painted spokes with polished cast-aluminum
Size 18 x 7.5 in.
Sahara (Optional)
Painted High Gloss Technical Gray with polished cast-aluminum
Size 18 x 7.5 in.
Rubicon (Standard)
Painted pocket with Mid-Gloss paint and polished cast-aluminum
Size 17 x 7.5 in.
Rubicon (Optional)
Painted pocket with Mid-Gloss paint and polished cast-aluminum
Size 17 x 7.5 in.
TIRES
Sport (Standard)
Size and Type: P245/75R17, on/off-road, black sidewall
Mfr. and Model: Michelin LTX MS2, Bridgestone Dueler HT 685, Bridgestone Dueler AT RH-S, Goodyear Wrangler Adventure AT
Revs per Mile (km):
665 (413) – Michelin LTX MS2
661 (411) – Bridgestone Dueler HT 685 & AT RH-S
668 (415) – Goodyear Wrangler Adventure AT
Sahara (Standard)
Size and Type: P255/70R18, on/off-road, OWL
Mfr. and Model: Bridgestone Dueler HT 685, Bridgestone Dueler AT RH-S, Goodyear Wrangler Adventure AT
Revs per Mile (km): 649 (403)
Rubicon (Standard)
Size and Type: LT285/70R17C, on/off-road, black sidewall
Mfr. and Model: BF Goodrich KO2 All-Terrain
Revs per Mile (km): 645 (401)
Four–wheel anti-lock brakes: Standard
Electronic stability control: Standard
All-speed traction control: Standard
